Trek Domane+ Road E-Bike - 2019, 56cm
$3299.00$2899.00
Smooth power and all-day comfort are features of the Trek Domane+, an electric road bike designed for endurance. Its 500 Series OCLV Carbon frame combines a Bosch Performance Line Speed motor with traditional Domane compliance, providing up to 28 mph of pedal-assist for smooth cruising over long distances and uneven terrain. The endurance shape makes the ride steady and pleasant for hours in the saddle, while the inbuilt 500Wh battery offers outstanding range. It provides dependable performance and assured stopping power thanks to its hydraulic disc brakes and SRAM Force 11-speed transmission. The Domane+ combines Trek's road pedigree with a natural pedalling feel to make long rides quicker, simpler, and more pleasurable without sacrificing the essence of a real road bike.
The 2019 Domane+ is designed to flatten hills and extend your range without sacrificing the comfortable, stable ride that the Domane family is known for . Its key features focus on powerful assistance and all-day comfort.
Powerful Bosch Drive System: At its core is a Bosch Performance Speed mid-motor (350 watts, 63Nm of torque) that provides assistance up to 28 mph (45 km/h) . It's paired with a fully integrated Bosch PowerTube 500Wh battery, neatly hidden in the down tube .
IsoSpeed Comfort Technology: The frame features Trek's proven Rear IsoSpeed decoupler, which allows the seat tube to flex independently, absorbing fatiguing bumps in the road for a smoother, more comfortable ride over long distances .
Endurance Road Geometry: The bike is built on the same endurance road geometry as the non-electric Domane, meaning a taller head tube for a more upright riding position and a longer wheelbase for confident stability .
High-Performance 1x Drivetrain: It features a SRAM Force 1 groupset, an 11-speed professional-level component group. This setup offers crisp, intuitive shifting and a wide gear range (11-36t cassette), made versatile by the powerful motor .
Integrated Features for Versatility: The bike comes stock with integrated front and rear lights powered by the main battery, hidden fender mounts, and clearance for tires up to 35mm, making it ready for commuting, light gravel, or long-distance touring .
Proper fit is crucial for road bike performance and comfort. Here are the detailed specifications and geometry for the 2019 Domane+ in size 56cm.
Rider Height Recommendation: The size 56cm is generally recommended for riders between approximately 172cm and 181cm (5'8" to 5'11") .
Frame Material: 500 Series OCLV Carbon
Key Geometry & Size Details (56cm)
Measurement | Value |
|---|---|
Weight | Approx. 17.2 kg (37.9 lbs) |
Wheelbase | 1021 mm |
Head Tube Angle | 71.9° |
Seat Tube Angle | 73.1° |
Chainstay Length | 440 mm |
Bottom Bracket Drop | 78 mm |
Fork Offset (Rake) | 50 mm |
Standover Height | 766 mm |
Component | Specification |
|---|---|
Frame | 500 Series OCLV Carbon, Rear IsoSpeed, tapered head tube, internal battery, flat mount disc, 12x142mm thru-axle, hidden fender mounts |
Fork | Domane+ carbon steerer and crown, flat mount disc, 12x100mm thru-axle |
Motor | Bosch Performance Speed, 350 watt, 63Nm torque, 28 mph / 45 km/h max assist |
Battery | Bosch PowerTube 500Wh (integrated, removable) |
Display/Remote | Bosch Purion |
Rear Derailleur | SRAM Force 1, medium cage, 11-speed |
Shifters | SRAM Force 1, 11-speed |
Cassette | SRAM PG-1170, 11-36, 11-speed |
Chain | SRAM PC-1170 |
Crankset | Praxis, Carbon E-Bike, 44T chainring |
Brakes | SRAM Force flat mount hydraulic disc |
Brake Rotors | SRAM Centerline (implied, based on Force package) |
Handlebar | Bontrager Elite IsoZone VR-CF, 31.8mm |
Stem | Bontrager Elite, 31.8mm, 7 degree, w/computer & light mounts |
Seatpost | Bontrager Ride Tuned alloy seatmast cap, 10mm offset |
Saddle | Bontrager Arvada Comp, steel rails |
Wheelset | Bontrager Paradigm Disc Tubeless Ready, 12mm thru-axle |
Tires | Schwalbe G-One Speed, TL Easy, 700x35c |
Lights | Front: Bontrager Lync (battery-powered), Rear: Bontrager Lync (integrated, battery-powered) |
